| Boom Length | 5.15 m |
| Arm Length | 2.62 m |
| Bucket Capacity (ISO heaped) | 0.62 m³ |
| Std. Operating Weight | 16,900 kg |
| Make & Model | ISUZU AI-4JJ1X |
| Rated Output | 89.2 kW/2 200min⁻¹ |
| Displacement | 2 999 ml(cc) |
| Main Pump | 2 variable displacement axial piston pumps |
| Max Pressure | 34.3 Mpa |
| (With Auto Power Boost) | 36.3 Mpa |
| Travel Motor | Variable Displacement Axial Piston Pumps |
| Parking Brake Type | Mechanical Disc Brake |
| Swing Motor | Fixed Displacement Axial Piston Motor |
| Travel Speed | 5.4/2.8 km/h |
| Traction Force | 161 kN |
| Grade Ability | 70% <35°> |
| Ground Pressure | 40 kPa |
| Swing Speed | 11.5 min⁻¹ |
| Bucket | 112 kN |
| /With Power Boost | 118 kN |
| Arm | 79 kN |
| /With Power Boost | 84 kN |
| Fuel Tank | 300 L |
| Hydraulic Fluid Tank | 90 L |
