| Boom Length | 5.70 m |
| Arm Length | 2.94 m³ |
| Bucket Capacity (ISO heaped) | 0.80 m³ |
| Std. Operating Weight | 20,000 kg |
| Make & Model | ISUZU AI-4HK1X |
| Rated Output | 117.3 kW/1 800min⁻¹ |
| Displacement | 5193 ml(cc) |
| Main Pump | 2 variable displacement axial piston pumps with regulating system |
| Max Pressure | 34.3 Mpa |
| (With Auto Power Boost) | 36.8 Mpa |
| Travel Motor | Variable Displacement Axial Piston Motor |
| Parking Brake Type | Mechanical Lock Brake |
| Swing Motor | Fixed Displacement Axial Piston Motor |
| Travel Speed | 5.6/3.4 km/h |
| Traction Force | 201 kN (20,496 kgf) |
| Grade Ability | 70% <35°> |
| Ground Pressure | 45 kPa |
| Swing Speed | 11.5 min⁻¹ |
| Bucket | 142 kN |
| /With Power Boost | 152 kN |
| Arm | 103kN |
| /With Power Boost | 110 kN |
| Fuel Tank | 410 L |
| Hydraulic Fluid Tank | 240 L |
