| Power Type | Diesel |
| Rated Capacity | 2500kg |
| Load Center | 500mm |
| Mast Tilt | 6/120 |
| Min Turning Radius | 2300mm |
| Min Intersecting Aisle | 3950mm |
| Max Traveling Speed (load/ unload) | 18.5/20 km/h |
| Max Lifting Speed (load/ unload) | 560/580 mm/s |
| Max Gradient | 20% |
| Self Weight | 3500kg |
| S/P Tread (front/rear) | 970/980mm |
| Std Engine | XINCHAIb- C490BPG |
| Rated Power | 36.8kw |
| H1 STD Max Lifting Height | 3000mm |
| H2 STD Mast Lowered Height | 2135mm |
| H3 Free Lifting Height | 110mm |
| H4 Overhead Guard Height | 2130mm |
| L1 Overall Length (with fork) | 3670mm |
| L2 Axle Distance | 1650mm |
| L3 Front Overhang | 448mm |
| L4 Rear Overhang | 500mm |
| L5 Std Fork size (L5xWxT) | 1220 x 120 x 40mm |
| Min Ground Clearance Frame | 160mm |
| Min Ground Clearance Mast | 135mm |
| Overall Width | 1165mm |
