| Power Type | Diesel |
| Rated Capacity | 3500kg |
| Load Center | 500mm |
| Mast Tilt | 6/120 |
| Min Turning Radius | 2530mm |
| Min Intersecting Aisle | 4225mm |
| Max Traveling Speed (load/ unload) | 18.5/20 km/h |
| Max Lifting Speed (load/ unload) | 400/420 mm/s |
| Max Gradient | 20% |
| Self Weight | 4635kg |
| S/P Tread (front/rear) | 1030/980mm |
| Std Engine | XINCHAI A498BT1 |
| Rated Power | 36.8kw |
| H1 STD Max Lifting Height | 3000mm |
| H2 STD Mast Lowered Height | 2132mm |
| H3 Free Lifting Height | 170mm |
| H4 Overhead Guard Height | 2150mm |
| L1 Overall Length (with fork) | 3898mm |
| L2 Axle Distance | 1750mm |
| L3 Front Overhang | 498mm |
| L4 Rear Overhang | 580mm |
| L5 Std Fork size (L5xWxT) | 1220 x 125 x 50mm |
| M1 Min Ground Clearance Frame | 165mm |
| M2 Min Ground Clearance Mast | 132mm |
| Overall Width | 1250mm |
