| Power Type | Diesel |
| Rated Capacity | 8000kg |
| Load Center | 600mm |
| Mast Tilt | 6/120 |
| Min Turning Radius | 3680mm |
| Min Intersecting Aisle | 5806mm |
| Max Traveling Speed (load/ unload) | 25/27 km/h |
| Max Lifting Speed (load/ unload) | 400/430 mm/s |
| Max Gradient | 21/25% |
| Self Weight | 11700kg |
| S/P Tread (front/rear) | 1600/1700 mm |
| Std Engine | YUCHAI YC68125-T20 |
| Rated Power | 92kw |
| H1 STD Max Lifting Height | 3000mm |
| H2 STD Mast Lowered Height | 2854mm |
| H3 Free Lifting Height | 200mm |
| H4 Overhead Guard Height | 2580mm |
| L1 Overall Length (with fork) | 5204mm |
| L2 Axle Distance | 2500mm |
| L3 Front Overhang | 706mm |
| L4 Rear Overhang | 778mm |
| L5 Std Fork size (L5xWxT) | 1520 x 175 x 70mm |
| M1 Min Ground Clearance Frame | 280mm |
| M2 Min Ground Clearance Mast | 240mm |
| Overall Width | 2169mm |
