Dynapac CA1500D

Dynapac CA1500D

These tandem rollers are designed with efficiency in mind -
application efficiency, operator efficiency, compaction control efficiency and
service efficiency. Performance, visibility, operators comfort, compaction
control and serviceability for the new CC line will appeal to owners, operators
and service crews. The environmental benefits appeal to everyone. All models
have high frequency vibration as standard. There is a number of features to the
CC rollers to make servicing quick and easy, ensuring maximum uptime.

  • Max. operating mass8500 kg
    Operating mass (incl. Cab)7200 kg
    Module mass (front/rear)3600 kg / 3600 kg
    Speed range0 - 12 km/h
    Vertical oscillation±9°
    Max. theoretical gradeability55 %
    Centrifugal force (high/low amplitude)133 kN / 72 kN
    Nominal amplitude (high/low)1.8 mm/0.8 mm
    Static linear load (front/rear)21 kg/cm
    Vibration frequency (high/low amplitude)32 Hz/36 Hz
    EngineCummins QSB 3.3 IIIA/T3
    Rated power, SAE J199574 kW (99 hp ) @ 2,200 U/Min.
