| Deck Ride Height | 950 mm |
| Deck Width | 2,490 mm |
| Deck Length | 10,510 mm |
| Forward Length | 9,200 mm |
| Rear Overhang | 4,210 mm |
| Top Deck | 4,000 mm |
| Deck Type | Bottom – HT Steel, Top 300 x 50 mm Treated Pine |
| Axles | 17.5” MTE Drum Brake Axles with 7.5” x 12.5” Brakes |
| Suspension | MTE Air Suspension |
| Brakes | Knorr EBS Braking System |
| Capacity (GVW) | 40,000 kg |
| Gooseneck | Fixed |
| Rub Plate | Fixed Single Position, 1270 mm - Height |
| King Pin | Retention Type 50mm |
| Ramps | 2700 mm x 900 mm Light Weight Ramps |
| Landing Legs | Full Weight Wind Up Landing Legs |
| Hydraulic Supply | Truck Hydraulics |
| Lights | LED |
