| Boom Length | 6.45 m |
| Arm Length | 3.25 m |
| Bucket Capacity (ISO heaped) | 1.40 m³ |
| Std. Operating Weight | 33600 kg |
| Make & Model | ISUZU AA-6HK1X |
| Rated Output | 202 kW (271 HP) / 2000min⁻¹ |
| Displacement | 7790 ml |
| Main Pump | 2 variable displacement axial piston pumps with regulating system |
| Max Pressure | 34.3 Mpa |
| (With Auto Power Boost) | 37.3 MPa |
| Travel Motor | Double Variable Displacement Axial Piston Pumps |
| Parking Brake Type | Mechanical Lock Brake |
| Swing Motor | Fixed Displacement Piston Motor |
| Travel Speed | 5.5/3.2 km/h |
| Traction Force | 278 kN |
| Grade Ability | 70% <35°> |
| Ground Pressure | 63 kPa |
| Swing Speed | 9.6 min⁻¹ |
| Bucket Digging Force | 229 kN |
| (With Auto Power Boost) | 248 kN |
| Arm Digging Force | 164 kN |
| (With Auto Power Boost) | 178 kN |
| Fuel Tank | 580 L |
| Hydraulic Fluid Tank | 175 L |
